YOUR NEEDS
Suitable for these needs
- 01Before opening the mold, the appearance and assembly need to be confirmed
- 02Structural revision requires trial installation verification
- 03Physical samples required for display, review or testing
04 / PROTOTYPING
Prototyping
First make a visible and fitable sample, and discover problems before opening the mold.
Single entrustment is possible · Can be connected to subsequent R&D and processing
Service content
How can this service help you?
Select 3D printing, CNC prototype or other suitable proofing methods according to the verification goals. You can check the appearance proportions, parts coordination and usage, and you can also complete the assembly inspection of the complete machine prototype in conjunction with electronic devices.
YOUR DELIVERABLES
What will you get?
- 01Prototype samples with agreed quantity and materials
- 02Sample appearance or surface treatment results
- 03Agreed fitting and dimensional inspection records
- 04List of items requiring repair or modification
Before starting, prepare these
- 01
Three-dimensional model, engineering drawings and key dimensions
- 02
Purpose, material, quantity and appearance requirements
- 03
Required parts and testing requirements
Look at pictures and actual work
Put the work into practice.
Advancing around specific products and uses, each stage has results that need to be confirmed.
Verify first, then decide how to process
Check key coordination and structural issues in advance to reduce repetitions in subsequent mold development.
Fitting is not just about the appearance.
Check the fixing, matching and assembly and disassembly spaces, and record the problems found in the physical state.
Confirm modifications against the sample
Organize the parts that need adjustment into the same list, and then update the design document.
How do we advance
- 01
Confirm whether the sample is for appearance or testing
- 02
Examine documents to determine materials and production methods
- 03
Processing and post-processing, inspection of samples
- 04
Trial installation and verification, feedback on issues that need adjustment
Confirm first before starting work
Quotation and construction period
Workmanship, size, quantity, surface treatment and assembly requirements all affect lead time. Production will be arranged after the documents are confirmed; materials and equipment schedules must be checked first for expediting.
Send information and evaluate the project ↗FAQ
How to choose between 3D printing and CNC prototypes?
First look at the purpose, materials, structure, appearance and budget. Printing can be evaluated for complex shapes and early trial assemblies; CNC and other methods can be evaluated for samples that specify engineering plastics, metals or require specific processing surfaces.
If there is no 3D file, can I proof it directly?
Usually requires modeling first. We can provide physical objects, dimensional sketches or product requirements, and first evaluate reverse copying, appearance or structural design, and then proceed to sample production.
Communicate directly with your product owner
Get in touch
Send photos, drawings or requirements descriptions, and confirm together how to do it, what to deliver, and how long it will take.
